FV-05VQ5 (FV-05VQ3) Panasonic WhisperCeiling Ceiling Mounted Exhaust Fan

 50 CFM - 0.3 Sones - 4 Inch Duct

Housing: 7.88 Inches Deep x 10.25 Inches x 10.25 Inches

Panasonic Bathroom Fans: Panasonic ventilation fans are super quiet, energy efficient ceiling ventilation exhaust fans and are perfect for the bathroom - or just about anywhere.


Add this Panasonic Fan to the cart to see our low price

or CALL our Panasonic Ventilation Fan experts toll free! 888-875-9283.

Not sure which Panasonic exhaust fan you need? Call our Ventilation experts at 888-875-WAVE or Click here to use the Panasonic Fan Selection Tool.

Panasonic Whisper Ceiling 50 CFM Ceiling Mounted Bathroom Ventilation Exhaust Fan
FV-05VQ3 (50 CFM - 4 Inch Duct).

• Mounting Opening - 10.8 Inches x 10.8 Inches
• Grill Size - 13 Inches x 13 Inches
• Duct Size - 4 Inch diameter
• Super quiet operation
• ENERGY STAR(r) qualified
• Totally enclosed condenser motor for long life - rated for continuous run
• Easy installation (Double hanger bar system)
• Rust proof paint treatment on galvanized housing
• Built-in damper to prevent backdraft
• Contemporary grille design
• UL listed for tub/shower enclosure when used with a GFCI branch circuit wire
• Thermal fuse protection
• Meets Washington State Ventilation and Indoor Air Quality Code


Panasonic FV-05VQ5 Technical Specs

Air Volume (CFM) 50 (31 at 0.25 inches static pressure) Noise (sones)  Less Than 0.3 Power Consumption (Watts) 12.9     (12.8 at 0.25 inches static pressure) Energy Efficiency (CFM's-Watt) 3.9     (2.4 at 0.25 inches static pressure) Speed (RPM) 817     (1150 at 0.25 inches static pressure) Current (Amps) 0.11 Power Rating (V-Hz) 120-60 Motor Type Condenser Type of Motor Bearing Ball Thermal Fuse Protection Yes Blower Wheel Type Sirocco Duct Diameter (inches) 4 inches Mounting Opening (inches sq.) 10.88 inches Grille Size (inches sq.) 13 inches UL Listed for Tub-Shower Enclosure Yes, when used with a GFCI branch circuit wire Washington State VIAQ Code Yes Mfg in ISO 9001 Certified Facility Yes Super Quiet Operation Yes Energy Star Qualified Yes Totally Enclosed Condenser Motor Yes, for long life - Rated for continuous run Easy Installation Yes Rust Proof Paint Treatment Yes, on galvanized housing Built-In Damper Yes, to prevent back draft Contemporary Grille Design Yes Galvanized Steel for Long Life Yes Double Hanger Bar  Yes

So Quiet You Might Not Know it's On
This Panasonic WhisperCeiling Bathroom Fan model features a totally enclosed condenser motor and a large, double suction blower wheel to quietly move air. A small wheel turning very fast will create more noise than a large wheel turning more slowly for a given airflow. Our fan uses a wide blower wheel that moves a large amount of air at reduced RPMs. The blower wheel is also designed to draw air in from both sides, which helps keep the noise down, as there is more area for the air to enter the wheel. In fact, it is quiet enough that you might not even know it's on.

Continuous, Trouble-free Operation for Many Years
This Panasonic bathroom fan is designed to give you continuous, trouble-free operation for many years thanks in part to its high-quality components and permanently lubricated motors which wear at a slower pace. Also, since heat is always detrimental to motor life (the cooler the environment, the longer the motor will last), we designed the electrical configuration of this model's condenser motor to allow it to operate at lower temperatures, increasing the life of the motor and bearings. And, the fan housing is made of heavy-gauge zinc galvanized steel and painted to protect it from rust.

User-Friendly Installation
Detachable adaptors, firmly secured duct ends, adjustable mounting brackets (up to 26 inches), fan-motor units that detach easily from the housing and uncomplicated wiring all lend themselves to user-friendly installation. This model also features a double-hanger bar system for ideal positioning.

Energy Star® Qualified for Energy Savings
Energy Star qualified products feature super-quiet operation and high CFM-to-Watt efficiency. The Energy Star program was created to help consumers identify products that can save them money and protect the environment by saving energy. As an Energy Star partner, all our fans are Energy Star qualified and labeled accordingly.

Tired of Cold Air Coming Through Your Ventilation Fan?
This Panasonic exhaust fan has a built-in damper to prevent backdraft, which helps to prevent outside air from coming through the fan. Also, thanks to our efficient, cool running motors and fluorescent bulbs, it does not create excessive heat-a common problem with recessed lighting fixtures and some competitors' fan-light combinations. Loose fill or batt insulation can be placed directly over the fan housing to prevent heat from escaping.
